Diamond Pistons 10101-4 GM Ecotec Street Strip Series
GM Ecotech 4 cylinder
10101-4
Forced pin oilers from the oil ring; Pin Fitted; 3D Pockets; Pins, Lock's & Support Rails (if required) included
Pricing:
$816.85
Description
| Product Specifications | Details |
|---|---|
| Item Number | 10101-4 |
| Engine Make | Chevrolet |
| Bore | 85.98mm |
| Stroke | 3.386 |
| Rod | 5.725 |
| Comp Height | 1.257 |
| Weight | 358 |
| Pin | .906 x 2.500 |
| CC | 1.0cc |
| Comp Ratio | 9.5 |
| Cylinder Head Chamber CC | Factory |
| Ring Thickness | 1.2mm x 1.5mm x 2.8mm |
| VP Intake Depth | 0.077 |
| VP Exhaust Depth | 0.091 |
| Cylinders | 4 |
| Barcode ID | 10101-4 |
| Class | 15 |
| Product Relations | Details |
|---|---|
| Product Line | GM Ecotech 4 cylinder |
| Pins Included | Y |
| Pin Part# | G9062500155 |
| Rings Included | Y |
| Ring Part# | 09143385 |
| Rails Included | N |
| Support Rail Part# | N/A |
| Locks Included | Y |
| Lock Ring Part# | 015103-8 |
| Country of Origin | USA |
Details
- 10101-4
- 10101-4
- Diamond Racing - Pistons
- New
Shipping Information
- Item Requires Shipping
- 12.0 lbs.
- W5.0000” x H12.0000” x L13.0000”
